## Plotting multiple curves

You will often want to plot more than one curve on a single graph, all sharing the same axes. This is simple in gnuplot: just separate the functions or datafiles by commas, and gnuplot will plot them in a sequence of colors or curve styles, with a legend so you can identify them. The following figure shows the plotting of multiple curves:

It will be useful to have some datafiles on your disk for use with some of the plotting recipes. You could make them by hand with a text editor or write a program in your favorite language to generate them, but gnuplot can do this itself. To make a file with data that forms a parabola flipped upside down, tell gnuplot to `set table 'parabola.text'`. Make sure to include the quotes around the filename. Then say `plot -x**2`. This writes a table out to the file `parabola.text` rather than making a picture. Now, say `unset table`. You should have a file called `parabola.text` in the directory in which you started gnuplot. Keep it around so we can use it later.

### How to do it…

After setting your terminal back to the graphics device you want to use at the gnuplot console, type the following command:

`plot [-1:1] 'parabola.text', -x, -x**3`

### How it works…

Gnuplot plots the curves using three different colors, dash styles, or line thicknesses, depending on the terminal in use, with a legend so you can tell them apart. The functions are plotted as smooth curves, as we did earlier, and the data from the file is plotted as a series of points, by default; one for each point in the range. This can all be adjusted, as we shall see in Chapter 3, Applying Colors and Styles.

Take a look at the datafile that gnuplot created to see the format it understands. After several comment lines beginning with the "#" character, we find a series of x coordinates and y values. The last character on each of these lines is a letter: "i" if the point is in the active range, "o" if it is out of range, or "u" if it is undefined.
