## Making a scatterplot

If you are in possession of a collection of measurements that, as is usually the case, is subject to random errors, an attempt to simply plot a curve through the measurements may result in a chaotic graph that will be difficult to interpret. In these cases, one usually begins with a scatterplot, which is simply a plot of a dot or small symbol at each data point. An examination of such a plot often leads to the discovery of correlations or patterns.

To make this recipe interesting, we need some slightly random-looking data. You may have some available, in which case you merely need to ensure that it is in a format that gnuplot can read. Simply arrange the data so that each line of the file contains one data point with space-separated x and y values:

```x1 y1
x2 y2
...```

Then name the file `scatter.dat`.

If you don't have such a file of your own handy, use the one called `scatter.dat` that we have provided. Make sure that the file is in the directory in which you have started gnuplot, so that the program can find it.

### Tip

Some of the recipes in this book will not work as intended if entered in the same interactive session unless you give the `reset` command first. This is because these scripts make settings that change gnuplot's default behavior.

Now simply tell gnuplot:

`plot 'scatter.dat' with points pt 7`

If you are using the file we provided, you will get a plot similar to the one shown in the previous figure.

### There's more…

You can plot the points using different symbols. Try `plot 'scatter.dat' with dots` to get the smallest dot available to your terminal. For use with scatterplots of very large datasets, try the following command:

`plot 'scatter.dat' with points pt n`

With different integers for `n`. `pt` stands for pointtype, and the different pointtypes available are dependent on your terminal. Simply type `test` in gnuplot to see a demonstration of all the pointtypes available for the currently selected terminal. You can find more about point and line styles in Chapter 3, Applying Colors and Styles.
